| CPU | Intel® Socket 2066 Core™ X-Series Processors Supports Intel® Virtual RAID on CPU (VROC) * The Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types * Refer to www.asus.com for CPU support list |
| Chipset | Intel® X299 |
| Memory | - Intel® Core™ X-series Processors (6-core above) 8 x DIMM, Max. 128GB, DDR4 4200(O.C.)/4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory - Intel® Core™ X-series Processors (4-core) 4 x DIMM, Max. 64GB, DDR4 4200(O.C.)/4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory - Supports Intel® Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU. |
| Multi-GPU Support | - Supports NVIDIA® 4-Way SLI™ Technology - Supports AMD 4-Way CrossFireX Technology |
| Expansion Slots | 7 x PCIe 3.0/2.0 x16 (single x16 or dual x16/x16 or triple x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8/x8/x8/x8) |
| Storage | - Intel® X299 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) 8 x SATA 6Gb/s port(s) 2 x U.2 connector*1 - Support Raid 0, 1, 5, 10 - Support Intel® Rapid Storage Technology enterprise 5.1 for X-Series(6-core and above) CPU RAID - Supports Intel® Smart Response Technology - Intel® Rapid Storage Technology 15 support - Intel® Optane™ Memory Ready - Intel® Virtual RAID (VROC) support for CPU RAID |
| LAN | - Intel® I210-AT, 1 x Gigabit LAN Controller(s) - Intel® I219-LM , 1 x Gigabit LAN Controller(s) |
| Audio | Realtek® ALC S1220A 7.1-Channel High Definition Audio CODEC - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking - High quality 120 dB SNR stereo playback output (Line-out at rear) and 113 dB (Line-in) Audio Feature : - DTS Connect - DTS Headphone:X - Audio amplifier: Provides the highest-quality sound for headphone and speakers - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity - Unique de-pop circuit: Reduces start-up popping noise to audio outputs Separate layer for left and right track, ensuring both sound deliver equal quality |
| USB Ports | Intel® X299 Chipset : - 8 x USB 3.1 Gen 1 port(s) (6 at back panel, , 2 at mid-board) Intel® X299 Chipset : - 4 x USB 2.0 port(s) (4 at back panel, ) ASMedia® USB 3.1 Gen 2 controller : - 2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A + USB Type-CTM) ASMedia® USB 3.1 Gen 2 controller : - 1 x USB 3.1 Gen 2 port(s) (1 at mid-board) |
| Special Features | OC Design - ASUS PRO Clock II Technology 5-Way Optimization by Dual Intelligent Processors 5 - 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo Core App TPU Fan Xpert4 - Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control ASUS 5X Protection III : - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage - ASUS Overvoltage Protection: World-class circuit-protecting power design - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! - ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention - ASUS ESD Guards - Enhanced ESD protection ASUS EPU : - EPU ASUS Digital Power Design : - Industry leading Digital 8 Phase CPU Power Design - Industry leading Digital 2 Phase DRAM Power Design AURA : - Aura RGB Strip Headers - Aura Addressable Strip Header(s) ASUS Exclusive Features : - AI Suite 3 - Ai Charger+ - Crystal Sound 3 ASUS EZ DIY : - ASUS CrashFree BIOS - ASUS EZ Flash - ASUS USB BIOS Flashback - Multi-language BIOS ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector M.2 and U.2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M.2 and U.2) Asus Control Center (ACC) IT management software supported |
| Operating System Support | Windows® 10 64-bit |
| Back I/O Ports | - 2 x LAN (RJ45) port(s) - 1 x USB 3.1 Gen 2 (teal blue)Type-A - 1 x USB 3.1 Gen 2 (black)USB Type-CTM - 6 x USB 3.1 Gen 1 (blue) - 4 x USB 2.0 (one port can be switched to USB BIOS Flashback) - 1 x Optical S/PDIF out - 1 x USB BIOS Flashback Button(s) - 1 x 8-channel Audio I/O |
| Internal I/O Ports | - 1 x Aura Addressable Strip Header(s) - 2 x U.2 port - 1 x AAFP connector - 1 x Aura RGB Strip Header - 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) - 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) - 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) - 1 x TPM header - 1 x COM port(s) connector(s) - 8 x SATA 6Gb/s connector(s) - 1 x VROC_HW_Key - 1 x CPU Fan connector(s) - 1 x CPU OPT Fan connector(s) - 2 x Chassis Fan connector(s) - 1 x AIO_PUMP connector - 1 x Thunderbolt header(s) - 1 x 24-pin EATX Power connector(s) - 1 x 6-pin ATX Power connector - 2 x 8-pin ATX 12V Power connector(s) - 1 x EZ XMP switch - 1 x 5-pin EXT_FAN(Extension Fan) connector - 1 x Power-on button(s) - 1 x Reset button(s) - 1 x Clear CMOS button(s) - 1 x Water Pump header (4-pin) - 1 x System panel connector - 1 x Thermal sensor connector - 1 x USB 3.1 Gen 2 front panel connector - 1 x CPU_OV jumper - 1 x MemOK! Button - 1 x M.2 Fan Header |
| Form Factor | CEB Form Factor 12 inch x 10.5 inch ( 30.5 cm x 26.7 cm ) |
| Weight | Color Box(3-in-1) - Net Weight: 5.55kg - Gross Weight: 8.06kg Bulk Pack(5-in-1) - Net Weight: 6.99kg - Gross Weight: 9.37kg |
| Environment | - Operation temperature: 10℃ ~ 35℃ - Non operation temperature: -40℃ ~ 70℃ - Non operation humidity: 20% ~ 90% ( Non condensing) |
| Note | *Intel® VROC is supported via RSTe, and Intel® VROC_HW_key. VROC_HW_Key is purchased separately. NVMe RAID type and function will depend on the Intel® VROC_HW_key installed. PCIEX16_1 to PCIEx16_3 & PCIEX16_4 to PCIEx16_7 support Intel® VROC separately. *1. The U.2 connectors are only supported on 44-Lane CPUs. |
